Now’s the time to install our Headers. We have a set of silver powdercoated wet LS headers from Lightning. Because we decided on a (much maligned) carbureted application, these headers won’t need to have an O2 sensor provision that an EFI application would have. Follow along as we install the headers on the engine and install the water tree and lines to the thermostat housing.
Category: Modifications
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 Installing the Carburetor
This week we install the 650 CFM Quick Fuel Carburetor on our LS motor. We had many questions on why we chose to use a carburetor rather than EFI. We did so for a couple reasons. 1), its more cost effective and 2) we don’t have to run an O2 sensor. We’re using a 1″ carb spacer and 1″ extended length mounting studs with our application.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 Aligning the Engine and Pump with the LS Engine Mount Rail Kit
We’ve installed the LS Engine Mount Rail Kit in our stringers and mounted the engine. Now we’re going to go over the alignment of the engine and the pump in relation to the rails.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 INSTALLING THE FRONT MOTORS MOUNTS AND THERMOSTAT CROSSOVER
This week on our LS Marine Engine conversion were adding the front motor mounts and the LS thermostat crossover system. With these parts installed we’re nearly ready to install the engine in the stringers.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 INSTALLING THE CONTROL BOX AND WIRE HARNESS CONNECTIONS
Making the engine run requires connecting up the control box and the wire harnesses. In this video we go through the basics of what connections need to be made to get the electrics hooked up.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 INSTALLING THE REAR ENGINE MOUNTS AND BELLHOUSING
We’re back with the next installment of our LS Marine conversion. Today we’re adding the rear motor mount plate from the Hardin Marine LS Engine Rail Kit and a polished bellhousing to cover the flexplate and driveline assembly.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 INSTALLING ENGINE TO JET DRIVE PTO & DRIVELINE ASSEMBLY
In the latest installment of its video-based series focused on converting a General Motor LS automotive engine for marine applications, the crew at Powerboat1.com tackles the next step in showing one of the possible combinations this powerplant could be used in.
Rick Bourns, the video host of Powerboat1.com and project and research leader for CP Performance. “Prepping this particular engine for say a Berkeley jet driven boat is a snap once we identify the matching components” .
PB1’s own Rick Bourns takes us through Identifying the different Styles of GM LS Crankshafts. The GM LS1, 2, and 3 series engines were offered in two different crankshaft end styles. The was based on what the intended use of truck or automobile might be. In this episode Rick shows us the correct Power Take-Off (PTO) and U-Joint Driveline Assembly that Hardin Marine has developed to make such a conversion a snap. With this type of detailed tech advise available these folks are turning these projects into true do- it-yourself types of projects
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 – INSTALLING THE INTAKE MANIFOLD
This week on the LS build we install the new intake manifold as we inch closer and closer to finishing the engine!
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 – Installing the New Marine Oil Pan
Moving on to the next step in our marine LS Engine build, we take off the old automotive oil pan and pickup and install a marine oil pan and pickup from Dooley.
-
LS MARINE ENGINE CONVERSION: GM LS 4.8, 5.3, 6.0, 6.2 – Laying out the Parts We Need
Our LS Engine project is moving along! We’ve stripped off the old junky automotive parts from this engine and we’ve lined up what parts we need to make this build a reality. Follow along as we go over the parts needed to make this a complete working marine LS engine.
